1050 aluminum foil

1050 aluminum foil
Grade: 1000 Series
Shape: Roll
Alloy:1050
MOQ: 1 Ton

SKU: 1050 aluminum foil
General Details

PRODUCT INTRODUCTION

The instruction of 1050 aluminum foil:

1050 aluminium is an aluminium-based in the “commercially pure” wrought family (1000 or 1xxx series). It is commonly used in the electrical and chemical industries, on account of having high electrical conductivity, corrosion resistance, and workability. 1050 aluminum foil alloy is also sometimes used for the manufacture of heat sinks, since it has a higher thermal conductivity than other alloys. It has low mechanical strength compared to more significantly alloyed metals.

Owing to the good conductivity and good price,1050 aluminium foils are widely used for dry type transformer windings in recent years.

Properties of 1050 aluminum foil:

Grade: 1000 SeriesSurface Treatment: Mill Finish

Shape: Roll

Alloy:1050

Temper:HO,H18,H14,H24,H26,H16

Thickness:0.06-0.2mm

Width:100-1500mm

Chemical composition of 1050 aluminum foil:

Si Fe Cu Mn Mg Cr Zn Ti Others Al
MAX. MAX. MAX. MAX. MAX. MAX. MAX. Individual Total Min
0.25 0.40 0.05 0.05 0.05 0.05 0.05 MAX.0.03 99.50

Feature of 1050 aluminum foil

1.Thin and light;

2.Super extractive;

3.Good mechanical strength;

4.High thermal conductivity and electric conductivity;

5.Excellent silvery white luster,beautiful appearance.

packing and delivery

Packaging and Delivery of 1050 aluminum foil:

Packaging Details:waterproof paper or plastic cover the package ,then make the wooden pallet . eye to wall or eye to sky

Delivery Detail:20-25 days once received the deposit
